U.S. Navy Ships in WWII Dazzle Camouflage 1944-1945

Auxiliary Ships

View by Design Number

Auxiliaries II

View by Design Number

for AGP-3

Design 11P

for AGP-3

Design Number Silhouette Ships Wearing Design
for AGP-3
Measure 31
Jamestown (AGP-3)
Drawing

The drawing for Measure 31 Design 11P for the motor torpedo boat tender USS Jamestown (AGP-3) dated June 23, 1944. Jamestown had been converted from patrol gunboat (PG-55). This drawing specified Measure 31 green colors of ocean green (5-OG) and navy green (5-NG) vertically with deck green (20-G) horizontally.

This is only drawing for Design 11P that has yet been found.

Original drawing source: NARA 80-G-174531 and 80-G-174532.
